Curtain Wall System

Customizable Curtain Wall System Manufacturer Options

Detailed configuration choices for designers, contractors, and procurement professionals

Selecting the right curtain wall system and manufacturer matters for performance, installation ease, project compliance, and lifecycle value. A well‑designed curtain wall system not only defines architectural expression but also ensures thermal comfort, air/water tightness, and structural resilience. Below is a comprehensive list of customizable options offered by professional curtain wall manufacturers to meet diverse project requirements.



1. Structural Frame Options

Aluminum Alloy Profile Grade

6063‑T5 / 6063‑T6 / 6082: Higher grade alloys with improved tensile strength for larger spans and taller façades

Thermal Break Frames: PA66 insulation strips inserted in aluminum profiles to reduce thermal bridging and improve energy efficiency

Profile Thickness & Reinforcement

Standard: 1.4–1.6 mm (residential or low‑rise)

Heavy Duty: 2.0 mm and above (high‑rise, commercial façades)

Reinforced Mullions and Transoms: For high‑wind zones or seismic regions

Surface Finish & Color Systems

Architectural Powder Coating — long‑term fade resistance, available in custom RAL colors

Anodized Finishes — enhanced durability and corrosion resistance

Wood Grain or Metallic Texture Films — premium aesthetic options



2. Glazing System Options

Glass Type & Performance

Clear Float Glass (6–12 mm)

Low‑E Insulated Units (double or triple glazing) for superior thermal performance

Laminated Safety Glass (e.g., 6.38 mm or 10.76 mm) for impact resistance and occupant safety

Tinted / Solar Control Glass for glare reduction and heat gain control

Gas Fill & Spacer Options

Argon or Krypton Gas Fill between panes for enhanced insulation

Warm Edge Spacers to minimize heat transfer at glass edges

Acoustic Performance

Laminated Glass with Acoustic Interlayers to reduce façade noise by 35–45 dB



3. Curtain Wall System Types

Stick Curtain Wall

Factory‑prepped profiles assembled on site

High flexibility for irregular openings

Unitized Curtain Wall

Large panels preassembled in factory

Reduced site labor, consistent quality, controlled tolerances

Semi‑Unitized Systems

Hybrid approach combining factory assembly with site installation efficiencies

Structurally Silicone Glazed (SSG)

Clean exterior line with concealed gaskets and structural sealants

Popular for modern high‑end architectural façades



4. Thermal & Weather Performance Options

Thermal Break Design

Standard PA66 thermal breaks

Upgraded multi‑chamber thermal break for extreme climates

Air & Water Sealing Systems

EPDM gaskets with multi‑layer weather barriers

Pressure equalized rainscreen design to reduce water infiltration under wind loads

Double & triple labyrnth seals to enhance air tightness

Wind Load Resistance Options

Tested and rated to meet required design pressures for local codes

Adjustable mullion sections to withstand high‑rise wind events



5. Hardware & Accessories

Anchoring & Fastening Systems

Customized anchors for concrete, steel or composite structures

Adjustable shims for shim‑free leveling

Opening Vent Options (Operable Curtain Walls)

Awning vents with friction stays

Casement vents with multi‑point locks

Hopper vents for controlled ventilation

Sun Shading & Screening

Exterior louvers (fixed or adjustable) integrated into curtain walls

Brise Soleil sunshade systems for solar control

Security & Safety Features

Blast‑resistant framing options for high‑risk zones

Anti‑lift hardware and restricted access systems



6. Size & Configuration Options

Panel Dimensions

Custom widths up to 3,000 mm (standard limits vary by system)

Custom heights up to 4,000 mm and beyond with reinforced frames

Geometry & Complex Shapes

Curved façades

Angular and triangular panels

Bay windows and corner details

Infill Materials

Glass

Metal panels (aluminum composite, steel)

Stone veneer or terracotta rainscreen panels



7. Performance Specification Options

Energy Performance Targets

Target U‑Value (e.g., ≤ 1.8 W/m²·K) for highly insulated façades

Solar Heat Gain Coefficient (SHGC) depending on orientation

Acoustic Targets

Low‑E + laminated acoustic combinations achieving Rw 38–45 dB

Fire & Smoke Control

Fire‑rated curtain wall elements (1 hr / 2 hr)

Smoke barriers integrated into vertical shafts



8. Automation & Smart Integration

Motorized Shades & Louvers

Controlled via wall switches, wireless remotes, or smart apps

Solar sensors for dynamic shading

Smart Ventilation Integration

Climate sensors tied to HVAC controllers

Automated vents for passive ventilation

Building Management System (BMS) Compatible

Curtain wall performance data can feed into central BMS dashboards



9. Quality Assurance & Certification

Reliable manufacturers provide documentation and test reports:

ISO9001 Quality Management System

NFRC (North America) energy labelling

CE compliance for Europe

AS/NZS 4284 or AS2047 (Australia/New Zealand) structural & water testing

Custom test reports for air, water, and wind resistance based on local code requirements



10. Project Support & Delivery Options

Pre‑Sale Engineering Support

Curtain wall shop drawings, BIM files, load calculations

3D detail modeling for design verification

Project Logistics

Numbered packaging for site installation efficiency

On‑site supervision and technical guidance

After‑Sale Support

Spare parts availability

Installation drawings with tolerances

Warranty documentation

Application of Curtain Wall System





High-Rise Office Buildings

Curtain walls are ideal for high-rise office towers, providing lightweight yet strong façades that can span multiple floors. They allow maximum natural light penetration, reducing reliance on artificial lighting and improving occupant comfort. High-performance glazing options ensure thermal insulation and noise reduction, critical for dense urban environments.



Hotels and Commercial Complexes

In hotels, shopping malls, and mixed-use commercial spaces, curtain walls deliver a modern, sleek exterior aesthetic while ensuring energy efficiency and weather resistance. Large glass panels create visually appealing entrances and atriums, enhancing the customer experience while maintaining UV protection and glare control.



Institutional and Healthcare Facilities

Curtain walls are used in hospitals, universities, and laboratories where controlled indoor environments are essential. They provide airtight and watertight façades, support natural daylighting for patient rooms or classrooms, and integrate operable vents or shading devices for ventilation management and thermal comfort.



Residential Towers and Apartments

High-rise residential buildings benefit from curtain walls by offering floor-to-ceiling glazing, balcony enclosures, and sound insulation from urban noise. Customized finishes and glazing types allow architects to enhance building identity, provide privacy, and maintain energy efficiency in various climates.

Why Choose Deslano As Your Curtain Wall System Manufacturer?



1. Advanced Engineering and Manufacturing Technology

Deslano integrates cutting-edge design software with automated production lines to ensure precise fabrication of curtain wall components. Our factory employs equipment imported from Germany, the USA, and Japan, enabling highly accurate aluminum extrusion, thermal break insertion, and frame assembly. This ensures that every unit meets strict structural, thermal, and acoustic standards.



2. Extensive Customization Options

We understand that each project is unique. Deslano offers comprehensive customization, including:

Frame profiles, thicknesses, and finishes (powder-coated, anodized, wood-grain or metallic textures)

Glazing options such as tempered, laminated, Low-E, and acoustic glass

Panel dimensions, geometries, and complex shapes (curved, angular, or corner panels)

Integration of operable vents, sunshades, or smart automation systems

This flexibility allows designers to realize their vision without compromise.



3. Superior Performance and Energy Efficiency

Deslano curtain walls are engineered for durability, weather resistance, and thermal efficiency. Our systems incorporate:

Multi-chamber thermal breaks to minimize heat transfer

High-performance gaskets and weather seals for airtight and watertight façades

Structurally reinforced frames to withstand wind, seismic forces, and heavy loads

Glazing combinations optimized for U-value, SHGC, and acoustic control

These features ensure comfortable interiors, lower energy costs, and long-term reliability.



4. Proven Quality and International Certifications

Quality is the cornerstone of Deslano’s manufacturing. Our curtain wall systems are rigorously tested and certified:

ISO9001 Quality Management System

CE compliance for European markets

NFRC energy efficiency labeling for North America

AS/NZS 4284 or AS2047 for structural and water penetration performance

These certifications guarantee compliance with global standards and give you confidence in your investment.



5. Comprehensive Project Support

From pre-sale engineering to post-installation support, Deslano provides end-to-end assistance:

Detailed shop drawings, BIM models, and structural calculations

Numbered packaging and installation supervision for faster, error-free assembly

Spare parts availability and warranty services for ongoing peace of mind

Our project support ensures that your curtain wall installation is smooth, efficient, and reliable from start to finish.

Ordering & Shipping Details



Minimum Order: 100 square meters (Minimum order quantities varies for different models and sizes . Please contact our customer service for details.).



Lead Time: 10-15 days for standard orders, depending on customization detail.



Transportation: We offer worldwide shipping. All doors are carefully packed with protective materials to prevent damage during transportation. If needed, we can also assist with installation instructions.



Payment Terms: Typically 30% deposit, with the balance due before shipment.

At Deslano Windoor, quality is not just a slogan, but a standard that runs throughout the entire production chain. Our quality management system is rigorously implemented and continuously optimized, and has successfully passed numerous international authoritative certifications such as AS2047, CE, CSA, NFRC, and Energy Star, providing strong assurance for product performance, safety, and durability.

Whether it's standard aluminum doors and windows or more complex, demanding impact-resistant hurricane-resistant systems, Deslano Windoor consistently adheres to high manufacturing standards, ensuring that every door and window is suitable for diverse climates and building projects worldwide.

Choosing Deslano Windoor eliminates the need for endless supplier comparisons; our manufacturing capabilities and quality system provide a solid foundation for long-term, stable cooperation.

A high-performance curtain wall system is more than an exterior façade—it is an integrated solution that supports structural performance, energy efficiency, long-term durability, and modern architectural aesthetics. Deslano provides end-to-end curtain wall system solutions tailored to commercial buildings, residential towers, retail spaces, hospitality projects, and custom architectural developments. Below is a comprehensive solution overview that highlights how a complete curtain wall system is designed, engineered, and delivered.

1. Structural & Engineering Solution

A reliable curtain wall begins with accurate engineering.
Deslano develops structural designs based on building height, wind load, seismic requirements, and installation conditions.

Key components of the structural solution include:

System Selection: Stick system, unitized system, semi-unitized system depending on project scale and installation speed.

Load-Bearing Analysis: Wind pressure calculations, deflection control, column anchorage strength, bracket distribution.

Thermal Break Structure: Polyamide strips and insulating spacers to reduce heat transfer.

Sealing Performance: Multi-layer EPDM gaskets, silicone sealant systems, and pressure-equalized chambers for water and air tightness.

Glass Optimization: Selection of double insulated, triple insulated, low-E, laminated, or tempered glass based on energy and safety requirements.

This ensures the façade can withstand environmental challenges while maintaining long-term structural stability.

2. Energy Efficiency & Performance Solution

Modern buildings demand strict performance standards.
Deslano curtain wall systems are engineered to help clients meet energy codes, green building certifications, and indoor comfort needs.

Performance-focused solutions include:

Low-E insulated glass packages to reduce solar heat gain and improve U-value performance.

Thermal break aluminum profiles to minimize heat conduction.

Integrated shading options such as exterior louvers, glass coatings, or internal blinds.

Sound insulation solutions, including laminated acoustic glass for hotels, offices, and residential towers.

Condensation prevention design, using optimized cavity ventilation and thermal barrier arrangement.

These solutions help reduce HVAC load, improve indoor comfort, and maintain consistent building performance throughout seasonal changes.

3. Design & Aesthetic Customization Solution

Every architectural project has a unique visual requirement.
Deslano provides a full set of design customization options to match the building’s style.

Design solutions include:

Profile Types: Slim frame, hidden frame, full-view structural glazing.

Glass Options: Clear, tinted, frosted, reflective, patterned, energy-saving coatings.

Aluminum Finishes: Powder coating (any RAL color), anodizing, wood-grain finish.

Module Dimensions: Custom panel sizes tailored to façade grid layout.

Sunshade Integration: Horizontal fins, vertical fins, perforated screens, customized shading modules.

These options allow architects and developers to achieve distinctive building façades without compromising performance.

4. Fabrication & Quality-Control Solution

A curtain wall system requires precise manufacturing to guarantee long-term stability.
Deslano executes strict production and testing procedures to ensure accuracy and durability.

Quality solutions include:

CNC automated machining for profile cutting, drilling, and milling.

Factory pre-assembly for unitized systems to minimize onsite errors.

Glass inspection procedures: tempering strength test, laminated PVB uniformity, IGU sealing integrity.

Material certification: Aluminum alloy 6063-T5/T6, sealant compliance, and hardware testing.

Environmental durability testing: water infiltration, air leakage, structural load test per international standards.

This ensures that every curtain wall panel meets high-precision engineering requirements.

5. Installation & On-Site Technical Support Solution

Proper installation is critical for curtain wall performance.
Deslano provides full-scope installation support to ensure efficient and secure site execution.

Installation solutions include:

On-site measurements and mounting bracket positioning guide.

Unitized installation process for high-rise buildings, reducing crane time and construction risk.

Waterproof detailing with silicone sealing, EPDM gasket installation, and drainage path design.

On-site inspection to verify alignment, anchor strength, and joint sealing performance.

Post-installation testing, such as water spray tests and air-tightness verification.

These services help minimize delays and ensure that the project progresses smoothly.

6. Long-Term Maintenance & After-Sales Solution

Deslano provides comprehensive maintenance planning to ensure the curtain wall system’s long-term performance.

Maintenance solutions include:

Cleaning guidelines for glass, aluminum, and sealant areas.

Regular inspection plans for drainage, gaskets, and sealant joints.

Replacement options for glass panels or worn hardware.

Remote technical assistance for troubleshooting and performance assessment.

This helps property owners protect their investment and maintain façade performance for years.

We're professional curtain wall system manufacturers and suppliers in China, specialized in providing high quality custom design service. We warmly welcome you to buy cheap curtain wall system for sale here from our factory. For price consultation, contact us.
